詳細說明
| 貨號 | 430901000 | 430902000 | 430903000 | 430905000 | 430910000 | |
| 型號 | KWG010 | KWG020 | KWG030 | KWG050 | KWG100 | |
| 額定載荷 | (Ton) | 1 | 2 | 3 | 5 | 10 |
| 測試載荷 | (Kn) | 14.71 | 29.42 | 44.13 | 61.29 | 122.58 |
| 最小轉彎半徑 | (M) | 1 | 1.1 | 1.3 | 1.4 | 1.7 |
| 尺寸 | A | 360 | 364 | 402 | 420 | 480 |
| B | 257 | 305 | 340 | 380 | 344 | |
| C | 180 | 205 | 252 | 290 | 354 | |
| D | 30 | 36 | 45 | 60 | 80 | |
| 推薦用工字鋼 | (mm) | 64-203 | 88-203 | 100-203 | 144-203 | 125-210 |
| 裝箱尺寸 | 整裝 | 350×270×190 | 360×310×220 | 420×360×270 | 440×400×310 | 500×360×370 |
| 散裝 | 280×200×160 | 320×200×170 | 350×280×190 | 400×310×220 | 410×380×250 | |
| 凈重 | Kg | 17.0 | 23.5 | 38.7 | 55.7 | 85 |
| 毛重 | Kg | 18.1 | 24.7 | 40.2 | 57.8 | 88 |
